**Please note that pictures may not properly represent actual products**

Style 622 | Tapping Sleeve | Carbon Steel | MJ Outlet Stainless Steel

Nominal Size: 4 in x 4 in
OD Range: 4.8 in

Product variant with selected options does not exist!

Price
$ 1,031.19
SKU: 622-048004MJ-231
Weight: 41.0 lb

Style 622 | Tapping Sleeve | Carbon Steel | MJ Outlet Stainless Steel



Typically ships in 7-10 business days



Product Features:

  • For 4 pipe and larger reducing and size-on-size flanged outlets. Available with -6threaded outlets.
  • Easy to install
  • Has range to reduce inventory
  • Meets AWWA C223 Standards
  • Epoxy Finish meets AWWA C213 Standards
  • Virtually 360 support of the pipe
  • Roll-resistant gasket will not bind
  • Gasket seal increases with line pressure
  • No special tools required to install the sleeve
  • Flanged outlets are recessed to accept tapping valves
  • Flexi-Coat Fusion-Bonded Epoxy Finish is standard for superior corrosion resistance
  • test outlet to allow hydrostatic pressure test before tapping the pipe (not available in standard 4 x 4)

Style 622 Smith Blair Spec Sheet

Materials:

  • Carbon Steel ASTM A283 Grade C. Type 304 Stainless Steel Optional
  • FLANGES AWWA C207 Class D ANSI 150# drilling. Recessed for tapping valve per MSS-SP 60. Optional Other types of flanges threaded outlets MJ outlets
  • GASKET Nitrile (Buna N) NSF-61 listed. Concave wedge gasket compounded to resist water oil acids alkalies most (aliphatic) hydrocarbon fluids and other chemicals
  • Temperature Range up to +180F
  • BOLTS & NUTS High strength low alloy Steel with heavy semi-finished hexagon nuts to ASTM A-307 (ANSI A21.11) standards. Optional Type 304 Stainless Steel bolts and nuts are coated to prevent galling
  • FINISH Flexi-Coat Fusion-Bonded Epoxy Finish
  • Working Pressure Up to 175 PSI
  • Pipe Applications Steel Cast Iron Asbestos Cement PVC
General Information

Q) When will my item ship?
A) Most items ship with-in 24-48 hrs.

Q) When will I get the tracking number?
A) Trupply ship items from multiple warehouses. Tracking number is available 24 hrs after shipping.

Q) What is your return policy?
A) Trupply offers 100% refund for unused items with-in 30 days.

Q) How can I get MTR?
A) MTRs are provided upon request. You can mention it at the time of order under "Order Notes" or email customer service.

Q) Who pays for shipping?
A) The buyer

Q) Where is Trupply located?
A) Trupply's main warehouse and office is in Houston TX.

Q) What are your customer service hours?
A) Monday to Firday 8 AM to 5 PM Central Time.

Q) I have more technical questions.
A) Email or call us for further help.

Country of Origin

Domestic Products Manufactured or Assembled in USA

Technical Specifications
Test Report, Data Sheet And Drawing

Coming Soon
