Full Encirclement Saddle | Type 5 | A234 WPB

Product Description

Full Encirclement Saddle | Type 5 | A234 WPB

Product Features:

Full Encirclement Saddles are used to provide reinforcement for branch outlets in accordance with ASME B31.3, B31.4, B31.8 and other applicable design codes. Although designed to fully encircle the run pipe, they are not meant to be pressure retaining.

Type 5 - Single piece construction, cut into three sections by splitting through the branch and through the run perpendicular to the branch

Material:

A234 WPB - The standard specification for piping fittings of wrought carbon steel and alloy steel for moderate and high temperature.
Additional A234 WPB Material Information

Main Pipe Run Nominal Size (inch)
Branch Outlet Nominal Size (inch)
$ 163,702.66

All Domestic products are melted and manufactured in USA.

All Dresser Products are domestically manufactured by GE / Dresser at the plant in Pennsylvania, USA.

All Import Valves, Hammer Unions, Y-Strainers & Frac Tank Supplies are assembled and tested in USA with components made in China

All Import Buttweld, Socketweld & Threaded Fittings are made in China/Taiwan/India

All Import Flanges are made in China/Taiwan/India

All materials are ASTM / ASME equivalent. Visit our Knowledge Central page for more information on material grades, material chemistry and ASTM, ASME & ANSI myth.

If you have any question, call 281.516.8100 or email sales@trupply.com.
