Style 473 | PipeLock Restraint | Steel Coupling

Product Images
**Please note that pictures may not properly represent actual products**

Product Variations
Nominal Size
OD Range
Sleeve Length
$ 263.52
Maximum quantity available reached.

Item Data

Bulk Discount Pricing

Sku: 473-03500396-203
Vendor: Smith Blair
Weight: 29.0 lb
5+
10+
50+
100+
3% Off
5% Off
7% Off
10% Off
Product Description

Style 473 | PipeLock Restraint | Steel Coupling

Product Features:

  • This is a fabricated Steel restraint coupling.
  • Application Joins and restrains a straight transition plain end PVC to plain end Ductile Iron or plain endPVC to plain end Steel.

Style 473 Smith Blair Spec Sheet

Materials:

  • SLEEVE ASTM A283 Gr. C or Carbon Steel having a minimum yield of 30000 PSI
  • FINISH Flexi-Coat Fusion-Bonded Epoxy
  • Mechanical restraint shall be an integral part of the follower gland utilizing multiple single tooth wedges
  • Comes as a complete unit
  • Use with the Multi-Seal Gasket for more flexibility ” mixing IPS and D.I. O.D. pipeBreakaway nut torque per wedge is 45 to 60 ft. lbs
  • Coupling is rated at the working pressure shown on the next pageLonger sleeves available
  • Cam-Lock„ Specifications
  • GLAND 65-45-12 Ductile Iron (ASTM A536)
  • WEDGES Single Tooth Ductile Iron heat treated for Ductile Iron pipe applications
  • ACTUATING BOLTS 60-40-18 Ductile Iron (ASTM A536)
  • BREAKAWAY NUTS Carbon Steel or Cast Iron
  • FINISH Gland is Flexi-Coat Fusion-Bonded Epoxy per AWWA C213 Wedges and actuating bolts are E-coated Epoxy
  • Kit Specifications
  • GASKET SBR Standard Mechanical Joint. ANSI/AWWA C111/A21.11 SBR or Multi-Seal Gasket
  • STUDS/NUTS High strength low alloy per AWWA C111 Optional304 Stainless Steel fluoropolymer-coated nuts
  • Pipe Applications PVC x Ductile Iron or PVC x Steel
